‌Siemens Touch Screen‌

• ‌Product overview: Siemens touch screen, also known as the wonderful series of panels, is a user-friendly man-machine interface. It is available in SMART 700 IE V3 and SMART 1000 IE V3 models, designed specifically for use with the S7 - 200 SMART PLC.
• ‌Screen specifications: 7-inch and 10-inch two size, resolution of 800 480 and 1024 600 respectively, support K color true color display and energy-saving LED backlight.
• ‌Features: It has hardware real-time clock, trend view, recipe management, alarm function, data recording and other functions, and supports 32 languages. At the same time, the integrated Ethernet port and serial RS-422/485 can be adaptively switched, which is convenient to connect with a variety of PLCs.
• ‌Interface and communication: SMART LINE V3 also integrates USB 2.0 interface, which can connect keyboard, mouse and USB storage devices. Its dedicated configuration software is WinCC flexible SMART V3, which takes up a small space and is easy to use.

Siemens touch screen is widely used in industrial automation field due to its powerful function and friendly user interface.


Siemens Touch Screen Configuration Software User Guide:

• ‌Installation steps:

  • Download the WinCC_flexible_SMART_V4SP1.exe software.
  • Right-click and select Run as Administrator.
  • Follow the installation wizard to select the installation language and installation options.
  • After the installation is complete, choose whether to restart the computer immediately, if desired.

• ‌Key Features:

  • ‌Quickly customize graphic styles: Supports open, standardized hardware and software interfaces, can be integrated into production, automation and management layers, and connected to a variety of PLCs.
  • ‌Batch modification variable association: used for quick configuration, improve work efficiency.
  • ‌Dynamic renderings: such as pie charts, can be produced in batches through EXCEL chart function and imported into HMI, and related to actual variables to achieve dynamic display.

Siemens touch screen configuration software has powerful customization and integration capabilities, through simple installation steps and application of key functions, can meet a variety of industrial automation requirements 12.

Siemens Touch Screen Agents


To download and install Siemens configuration software, follow these steps:

‌Download software:

• Obtain software installation packages, such as WinCC_flexible_SMART_V4SP1.exe.

‌Install software:

1. ‌Run the installation package: Right-click on the downloaded software and select Run as Administrator.
2. ‌Select Language: Click Next after welcome page, select installation language as Simplified Chinese.
3. ‌Installation Settings: Check Overwrite Files and Don't Prompt, select Installation Path, and click Next.
4. ‌Accept License: Read and agree to license information, select Full Installation.
5. ‌Complete installation: Wait for the software installation to complete, and choose whether to restart the computer immediately according to the prompt.

Once installed, project configuration and programming can begin using Siemens configuration software1. If you encounter connection problems, you can add a communication driver to the WinCC project to ensure normal communication with devices such as PLCs.
