SIEMENS Shanghai Xinyishun Automatic Equipment Co., Ltd.

Contact: Wang Gong (Sales Engineer)

S7-300
power template
6ES7 307-1BA00-0AA0 Power Module (2A)
6ES7 307-1EA01-0AA0 Power Module (5A)
6ES7 307-1KA02-0AA0 Power Module (10A)
CPU
6ES7 312-1AE13-0AB0 CPU312, 32K RAM
6ES7 312-5BE03-0AB0 CPU312C, 32K Memory 10DI/6DO
6ES7 313-5BF03-0AB0 CPU313C, 64K Memory 24DI/16DO / 4AI/2AO
6ES7 313-6BF03-0AB0 CPU313C-2PTP, 64K Memory 16DI/16DO
6ES7 313-6CF03-0AB0 CPU313C-2DP, 64K Memory 16DI/16DO
6ES7 314-1AG13-0AB0 CPU314,96K RAM
6ES7 314-6BG03-0AB0 CPU314C-2PTP 96K Memory 24DI/16DO / 4AI/2AO
6ES7 314-6CG03-0AB0 CPU314C-2DP 96K Memory 24DI/16DO / 4AI/2AO
6ES7 315-2AG10-0AB0 CPU315-2DP, 128K RAM
6ES7 315-2EH13-0AB0 CPU315-2 PN/DP, 256K RAM
6ES7 317-2AJ10-0AB0 CPU317-2DP,512K RAM
6ES7 317-2EK13-0AB0 CPU317-2 PN/DP,1MB RAM
6ES7 318-3EL00-0AB0 CPU319-3 PN/DP, 1.4M RAM
memory card
6ES7 953-8LF20-0AA0 SIMATIC Micro Memory Card 64kByte(MMC)
6ES7 953-8LG11-0AA0 SIMATIC Micro Memory Card 128KByte(MMC)
6ES7 953-8LJ20-0AA0 SIMATIC Micro Memory Card 512KByte(MMC)
6ES7 953-8LL20-0AA0 SIMATIC Micro Memory Card 2MByte(MMC)
6ES7 953-8LM20-0AA0 SIMATIC Micro Memory Card 4MByte(MMC)
6ES7 953-8LP20-0AA0 SIMATIC Micro Memory Card 8MByte(MMC

switch template
6ES7 321-1BH02-0AA0 switch-in module (16 points, 24VDC)
6ES7 321-1BH10-0AA0 switch-in module (16 points, 24VDC)
6ES7 321-1BH50-0AA0 Input Module (16 Point, 24VDC, Source Input)
6ES7 321-1BL00-0AA0 switch-in module (32 points, 24VDC)
6ES7 321-7BH01-0AB0 switch-in module (16 points, 24VDC, diagnostic capability)
6ES7 321-1EL00-0AA0 switch-in module (32 points, 120VAC)
6ES7 321-1FF01-0AA0 switch-in module (8 points, 120/230VAC)
6ES7 321-1FF10-0AA0 switch-in module (8 points, 120/230VAC) connected separately to common potential
6ES7 321-1FH00-0AA0 switch-in module (16 points, 120/230VAC)
6ES7 321-1CH00-0AA0 switch-in module (16 points, 24/48VDC)
6ES7 321-1CH20-0AA0 switch-in module (16 points, 48/125VDC)
6ES7 322-1BH01-0AA0 Open module (16 points, 24VDC)
6ES7 322-1BH10-0AA0 Open module (16 points, 24VDC) High speed
6ES7 322-1CF00-0AA0 Open Module (8 points, 48-125VDC)
6ES7 322-8BF00-0AB0 Diagnostic capability of open module (8 points, 24VDC)
6ES7 322-5GH00-0AB0 Open module (16 points, 24VDC, independent contact, fault protection)
6ES7 322-1BL00-0AA0 Open Module (32 points, 24VDC)
6ES7 322-1FL00-0AA0 Open Module (32 points, 120VAC/230VAC)
6ES7 322-1BF01-0AA0 Open module (8 points, 24VDC, 2A)
6ES7 322-1FF01-0AA0 Open Module (8 points, 120V/230VAC)
6ES7 322-5FF00-0AB0 Open module (8 points, 120V/230VAC, independent contact)
6ES7 322-1HF01-0AA0 Open module (8 points, relay,2A)
6ES7 322-1HF10-0AA0 Open module (8 points, relay,5A, independent contact)
6ES7 322-1HH01-0AA0 Open module (16 points, relay)
6ES7 322-5HF00-0AB0 Open module (8 points, relay,5A, failsafe)
6 ES 7 322 - 1FH 00 - 0AA 0 Open Module (16 points, 120 V/230 VAC)
6ES7 323-1BH01-0AA0 8-point input, 24VDC;8-point output, 24VDC module
6ES7 323-1BL00-0AA0 16-point input, 24VDC;16-point output, 24VDC module
analog template
6ES7 331-7KF02-0AB0 Analog input module (8 channels, multiple signals)
6ES7 331-7KB02-0AB0 Analog input module (2 channels, multiple signals)
6ES7 331-7NF00-0AB0 Analog Input Module (8 channels, 15 bit accuracy)
6ES7 331-7NF10-0AB0 Analog Input Module (8 channels, 15 bit accuracy)4 channel mode
6ES7 331-7HF01-0AB0 Analog input module (8 channels, 14 bit accuracy, fast)
6ES7 331-1KF01-0AB0 Analog Input Module (8 channels, 13 bit accuracy)
6ES7 331-7PF01-0AB0 8 analog inputs, 16 bits, thermal resistance
6ES7 331-7PF11-0AB0 8 analog inputs, 16 bits, thermocouple
6ES7 332-5HD01-0AB0 Analog output module (4 channels)
6ES7 332-5HB01-0AB0 Analog output module (2 channels)
6ES7 332-5HF00-0AB0 Analog output module (8 channels)
6ES7 332-7ND02-0AB0 Analog output module (4 channels, 15-bit accuracy)
6ES7 334-0KE00-0AB0 Analog Input (4-way RTD)/Analog Output (2-way)
6ES7 334-0CE01-0AA0 Analog Input (4 channels)/Analog Output (2 channels)
attachment
6ES7 365-0BA01-0AA0 IM365 Interface Module
6ES7 360-3AA01-0AA0 IM360 Interface Module
6ES7 361-3CA01-0AA0 IM361 Interface Module
6ES7 368-3BB01-0AA0 Connection cable (1 m)
6ES7 368-3BC51-0AA0 Connection Cable (2.5 m)
6ES7 368-3BF01-0AA0 Connection cable (5m)
6ES7 368-3CB01-0AA0 Connection cable (10 m)
6ES7 390-1AE80-0AA0 Rail (480mm)
6ES7 390-1AF30-0AA0 Rail (530mm)
6ES7 390-1AJ30-0AA0 Rail (830mm)
6ES7 390-1BC00-0AA0 Guide rail (2000mm)
6ES7 392-1AJ00-0AA0 20 pin front connector
6ES7 392-1AM00-0AA0 40 pin front connector
function template
6ES7 350-1AH03-0AE0 FM350-1 Counter function module
6ES7 350-2AH00-0AE0 FM350-2 Counter function module
6ES7 351-1AH01-0AE0 FM351 Positioning function module
6ES7 352-1AH02-0AE0 FM352 Electronic Cam Controller + Configuration Pack CD
6ES7 355-0VH10-0AE0 FM355C closed-loop control module
6ES7 355-1VH10-0AE0 FM355S Closed loop control system
6ES7 355-2CH00-0AE0 FM355-2C Closed Loop Control Module
6ES7 355-2SH00-0AE0 FM355-2S Closed Loop Control Module
6ES7 338-4BC01-0AB0 SM338 Position Input Module
6ES7 352-5AH00-0AE0 FM352-5 High Speed Boolean Processor
6ES7 352-5AH00-7XG0 FM352-5 Feature Package
Communication templates
6ES7 340-1AH02-0AE0 CP340 Communication Processor (RS232)
6ES7 340-1BH02-0AE0 CP340 Communication Processor (20mA/TTY)
6ES7 340-1CH02-0AE0 CP340 Communication Processor (RS485/RS422)
6ES7 341-1AH01-0AE0 CP341 Communication Processor (RS232)
6ES7 341-1BH01-0AE0 CP341 Communication Processor (20mA/TTY)
6ES7 341-1CH01-0AE0 CP341 Communication Processor (RS485/RS422)
6ES7 870-1AA01-0YA0 Loadable drive MODBUS RTU master
6ES7 870-1AB01-0YA0 Loadable drive MODBUS RTU slave station
6ES7 902-1AB00-0AA0 RS232 Cable  5m
6ES7 902-1AC00-0AA0 RS232 Cable  10m
6ES7 902-1AD00-0AA0 RS232 Cable  15m
6ES7 902-2AB00-0AA0 20mA/TTY Cable  5m
6ES7 902-2AC00-0AA0 20mA/TTY Cable  10m
6ES7 902-2AG00-0AA0 20mA/TTY Cable  50m
6ES7 902-3AB00-0AA0 RS485/RS422 Cable  5m
6ES7 902-3AC00-0AA0 RS485/RS422 Cable  10m
6ES7 902-3AG00-0AA0 RS485/RS422 Cable  50m
6GK7 342-5DA02-0XE0 CP342-5 Communication Module
6GK7 342-5DF00-0XE0 CP342-5  Optical fiber communication module
6GK7 343-5FA01-0XE0 CP343-5 Communication Module
6GK7 343-1EX30-0XE0 CP343-1 Ethernet communication module
6GK7 343-1EX21-0XE0 CP343-1 Ethernet communication module
6GK7 343-1CX00-0XE0 CP343-1 Ethernet communication module
6GK7 343-1CX10-0XE0 CP343-1 Ethernet communication module
6GK7 343-1GX20-0XE0 CP343-1 IT  Ethernet communication module
6GK7 343-1GX21-0XE0 CP343-1 IT  Ethernet communication module (PROFINET support)
6GK7 343-1HX00-0XE0 CP343-1PN PROFINET Ethernet communication module
6GK7 343-2AH00-0XA0 CP343-2 AS-Interface
